KGP Gasoline Driven Portable Air Compressor Supplier – High Efficiency Screw Type for Construction & Mining
The KGP Series gasoline portable screw air compressor is the perfect choice for utility repairs, road maintenance, and small-scale construction where power and mobility are essential but a heavy diesel unit is not required.
Click the button to consult, and we will provide a fast quotation within 3 hours
Functional Configuration
- Honda GX630 Engine
- EU Stage V Emission Compliance
- Electric Cold Start System
- Key Ignition with Choke Control
- PE Protective Enclosure
- Custom RAL Color Options
- Aftercooler & Separator
- Condensate-free Compressed Air
- Integrated Control Panel
- Pressure Gauge, Runtime & Temp Sensor
- Foldable Mobility Handle
- Four Side Lifting Points
Performance Parameters
- Working Pressure Range
- 7–15 bar (101.53–217.56 psi)
- Free Air Delivery
- 0.9–1.6 m³/min (31.78–56.50 cfm)
- Rated Power
- 15.5 kW (20.79 hp)
- Fuel Tank Capacity
- 20 Litres
- Fuel Consumption (Full Load)
- 3.8 L/h
- Fuel Consumption (Unload)
- 2.8 L/h
- Overall Dimension
- 1300 × 1050 × 900 mm
- Net Machine Weight
- 200 kg
Why KGP Series Excels in Field Industrial Projects
What Industrial Buyers Usually Worry About
- Heavy diesel units that are overkill and difficult to move for small sites
- Piston compressors that lack the endurance for continuous operation
- Difficulty accessing specialized service for complex engine systems
- High transport costs for moving oversized air equipment between jobs
How This Product Reduces Procurement Risk
- Provide a lightweight yet powerful 7-10 bar screw air solution
- Deliver consistent, non-stop air flow that outlasts portable piston units
- Use globally recognized gasoline engine brands for easy local parts access
- Optimize equipment size for standard logistics and effortless onsite relocation
Recommended Applications
KGP Series – Portable Gasoline Air Compressor Advantages:
|
Petrol engine with electric starter
The compact engine is equipped with the environmentally friendly Honda petrol engine, which complies with the EU Stage V emissions standard. Convenient one-touch starting ensures that the compressor is always ready for immediate operation, and a large 20-litre fuel tank allows for long refuelling intervals.
Polyethylene housing available in special colours
The PE housing is available in the following special colours.
Blue – corresponds to RAL 5017, red – corresponds to RAL 3020, orange – corresponds to RAL 2009, white – corresponds to RAL 9010, green corresponds to RAL 6024 Other housing colours are available as chargeable options.
Aftercooler
Compact models can be operated with an external condensate treatment system. The racks are delivered ready for connection and are equipped with aftercoolers and condensate separators to provide cool, condensate-free compressed air. In addition, a combination of filters is available for supplying compressed air that is technically oil-free.
Frequently Asked Questions
The KGP gasoline series is ideal for users who need a lighter, more compact mobile solution for smaller-scale projects. Gasoline engines are generally easier to start in cold weather and have lower initial purchase costs, making them perfect for road maintenance, utility repairs, and smaller construction sites where a heavy diesel unit isn't necessary.
Yes. Despite its portable size, the KGP series utilizes high-precision screw airends and a robust gasoline engine designed for industrial durability. It provides a stable and continuous air supply at 7-10 bar, ensuring your pneumatic tools like jackhammers or sandblasting guns work without interruption.
Portability is a core feature of the KGP series. It is designed with a compact chassis and heavy-duty wheels, allowing a single operator or a small team to maneuver it easily around a job site or load it onto a standard pickup truck without needing specialized lifting equipment.
Maintenance is straightforward and cost-effective. Regular tasks include checking engine oil, cleaning or replacing the air filter, and monitoring the compressor oil level. Because we use widely recognized gasoline engine brands, spare parts and filters are easily accessible globally, minimizing your downtime.
The KGP series features an efficient oil-gas separation system, ensuring minimal oil carryover in the discharge air. This protects your downstream pneumatic tools from contamination, extending their service life and reducing the need for frequent tool maintenance.
Absolutely. As a global industrial supplier, KOTECH offers a comprehensive warranty and technical support for the KGP series. We provide detailed manuals and online engineering support to ensure your equipment operates at peak performance, no matter where your project is located.
KGP Series Gasoline Portable Selection Table
| Model | Flow rate-m3/min | Flow rate-cfm | Working pressure-bar | Working pressure-PSI | Engine Make | Engine Mode | Rated power-kW | Speed at full load-rpm | Fuel tank capacity-l | Operating weight-kg | Sound power level-dB(A) | Sound pressure level-dB(A) | Compressed air outlet |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KGP-1.6/7 | 1.6 | 57 | 7 | 100 | Honda | GX 630 | 15.5 | 2500 | 20 | 202 | ≤97 | 76 | 1 x G½ |
| KGP-1/10 | 1.0 | 35 | 10 | 145 | Honda | GX 630 | 15.5 | 2500 | 20 | 202 | ≤97 | 76 | 1 x G½ |
| KGP-0.9/15 | 0.9 | 30 | 15 | 215 | Honda | GX 630 | 15.5 | 2500 | 20 | 202 | ≤97 | 76 | 1 x G½ |
| KGP-1.6/7 | 1.6 | 57 | 7 | 100 | Honda | GX 630 | 15.5 | 3300 | 20 | 204 | Only for export outside the EU | Only for export outside the EU | 1 x G½ |
| KGP-0.9/15 | 0.9 | 35 | 15 | 215 | Honda | GX 630 | 15.5 | 2300 | 20 | 204 | ≤97 | 76 | 1 x G½ |
